Wafer Type Ball Valve

Product Model

VH-10W

Description

Wafer type ball valve is designed for compact pipeline installations where space is limited. Its face-to-face length is approximately half that of a standard flanged valve, reducing the pipeline footprint and lowering demand for pipe supports and mounting hardware. The short distance between the valve seat and the flange face minimizes the media retention zone, making it a practical choice for applications with high cleanliness requirements, such as food processing and pharmaceutical production.

VH-10W Wafer type ball valve fits between two pipe flanges using through-bolts and is available in GB or ASME/ANSI flange standards. Valve body material options include WCB, SS304 (CF8), or SS316 (CF8M). Standard features include a blow-out-proof stem. Optional accessories include an ISO 5211 mounting pad, a lockable handle to prevent accidental operation, and an antistatic device to eliminate static discharge risks.

Size Range: DN15 to DN100 (1/2″ to 4″)
Max. Allowable Operating Pressure: GB PN 16 / ASME Class 150
Temperature Range: -20°C to 180°C
Valve Material: WCB / SS304(CF8) / SS316(CF8M)
End Connection Type: Wafer Type Flanged
OEM Support: Yes

Send Inquiry Now

Meets Safety Standards

Technical Specifications

Size Range DN15 to DN100 (1/2″ to 4″)
Connection Standard GB ASME/ANSI
Max. Allowable Operating Pressure PN 16 Class 150
Face To Face Manufacturer Standard
Seat Material PTFE
Temperature Range -20°C to 180°C
Valve Body Material WCB / SS304(CF8) / SS316(CF8M)
End Connection Type Flanged
Testing Standard JB/T 9092 API 598
*Custom specifications are available
