2-piece flanged floating ball valve CF8 DN50- VINCER
2-piece flanged floating ball valve CF8 DN50- VINCER

2-Piece Flanged Floating Ball Valves

Product Model

VH-10F2PS

Description

2-piece Flanged Floating Ball Valve is a flanged ball valve for on/off flow control in small and medium-bore pipeline systems. Its simple structure, low operating torque, and ease of maintenance make it one of the most widely used ball valve types in industrial applications.

In a floating ball valve, the ball is free to move slightly within the valve body. When the valve closes, line pressure pushes the ball against the downstream seat to form a seal. The higher the upstream pressure, the tighter the seal becomes — a self-energized characteristic that makes floating ball valves well suited to low and medium-pressure pipeline service.

Available in GB, ASME/ANSI, JIS, and DIN standards, with body materials in WCB, SS304 (CF8), and SS316 (CF8M). Stem blow-out protection is standard; an anti-static device is available on request. Suitable for water treatment, chemical processing, food and beverage, pharmaceutical, and general industrial piping applications.

Size Range: DN15 to DN150 (1/2″ to 6″)
Max. Allowable Operating Pressure: GB PN 40 / ASME Class 300 / JIS 20 K
Temperature Range: -20°C to 180°C
Valve Material: WCB / SS304(CF8) / SS316(CF8M)
End Connection Type: Flanged
Connection Standard: GB / ASME / JIS / DIN
OEM Support: Yes

Send Inquiry Now

Meets Safety Standards

Technical Specifications

Size Range DN15 to DN150 (1/2″ to 6″)
Connection Standard GB DIN ASME/ANSI JIS
End Connection Type Flanged
Design Standard GB/T 12237 EN 1983; EN12516-1 ASME B16.34 JIS B2071
Flange Drilling HG/T 20592 DIN 2543-2545; EN 1092-1 ASME B16.5 JIS B2220
Face To Face GB/T 12221 DIN 3202 part1-F4; DIN 3202 part1-F5 ASME B16.10 JIS B2002
Testing Standard GB/T 13927; JB/T 9092 DIN 3230; EN 12266-1 API 598 JIS B2003
Max. Allowable Operating Pressure PN 16 or PN 40 PN 16 or PN 40 Class 150 or Class 300 10 K or 20 K
Seat Material PTFE
Temperature Range -20°C to 180°C
Valve Body Material WCB / SS304(CF8) / SS316(CF8M)
*Custom specifications are available
